Electropneumatic strapping head for steel strap

Light-duty strapping specialist
TITAN VS12-L-LD

Sealless strapping with 1 welding spot and a tension force of up to 10,000 N for strap widths of up to 19 mm.

Technical data

Technical specifications
TITAN VS12-L-LD

dimensions of the expansive package in mm 70
max. tension force in N 10,000
dimensions (L x W x H) in mm 700 x 400 x 600
max. weight in kg 120
kind of sealing TIG welding joint
  • electropneumatic
  • specialising in light-duty strapping
  • fast strapping cycles
  • smooth strap feed

The right steel strap

Regular duty steel strap for automatic machines Dimensions from 12.7 x 0.5 mm to 19 x 0.6 mm MEGABAND® Dimensions from 12.7 x 0.5 mm to 19 x 0.63 mm Megaflex I Dimensions from 16 x 0.5 mm to 19 x 0.63 mm

Designed for tough industrial conditions: the TITAN V12-L-LD is your pneumatic strapping head for steel strap, ideal for light-duty strapping applications.

As with all TITAN units in this series, sealing is performed sealless using the patented TITANARG® TIG welding joint, which is set by contactless welding. The benefit for you: an extremely high sealing force and reduced wear on the strapping head. The TITAN V12-L-LD operates with strap widths of 12.7 mm, 16 mm and 19 mm and, with a tension force of up to 10,000 N, delivers the necessary power for light-duty strapping of items such as split coils, sheet packs or timber. This is the way to do it!

Here’s where the piggy bank squeaks: thanks to the TITANARG® sealing system’s contactless welding, the VS12-L-LD minimises wear and maintenance costs.

Even more TITAN for your strapping

Consumables: straps and seals, made by TITAN

Practical accessories for efficient strapping

TITAN packaging lines: from production to lorry

100% TITAN quality from our own production
